UNV 4K UltraHD NDAA-Compliant 16-Channel Hybrid Digital Video Recorder with support for TVI, AHD, CVI, CVBS, and 16 Additional IP Inputs (XVR302-16U3)
- Support H.265/H.264 video formats
- Support audio over coaxial cable(TVI cameras)
- Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
- 16-channel BNC input
- Support 1-ch CVBS output, 1-ch VGA output, 1-ch HDMI output at up to 4K(3840 x 2160) HDMI and VGA simultaneous output
- Long transmission distance over coaxial cable
- Support mainstream cameras of ONVIF and RTSP protocols
XVR302-16U3
16 IP Recorder
4K Ultra HD
Up to 4K Ultra HD Resolution
2 SATA HDD
Up to 16TB each
3 Year Warranty
Warranty Information
Video recorders are the heart of your cctv system. With the XVR302-16U3 you can be sure that your security cameras are in good hands. This HD-TVI video recorder is perfect for medium-large installations with up to 16 security cameras.
In addition to being a 16 channel DVR, the XVR302-16U3 is also considered a Tribrid DVR, which means you also have the ability to add up to 16 IP security camera ; effectively making this 32 channel DVR.
The XVR302-16U3 is just what your system needs to ensure fast, powerful, and reliable surveillance 24/7.
Recording Schedules
If you want 24/7 video recording, the XVR302-16U3 DVR is a great choice. You can rest assured that your surveillance system never misses a moment with it's ability to add 2 Hard Drive/s, Up to 16TB each.
You can also setup custom recording schedules based on days and times of the week, or based on events such as motion detection.
NDAA Compliant
This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.
Local & Remote Viewing
This DVR can be used with or without being connected to the Internet. You can view your DVR locally by connecting it to any HD-TV or monitor. If connected to the internet, you are also able to view your DVR remotely by downloading the following app to your smart device.
| SPECIFICATION | |
|---|---|
| IP Channels | 16 |
| Analog Channels | 16 |
| Max Resolution | 4K Ultra HD |
| Max Incoming Bandwidth | 80Mbps |
| Max Outgoing Bandwidth | 160Mbps |
| Video Compression | Ultra H.265|H.265|H.264 |
| Hard Drive Slots | 2 |
| Hard Drive Capacity | Up to 16TB each |
| Audio I/O | 4ch / 1ch |
| Alarm I/O | 8ch / 4ch |
| Onvif Compatible | Yes |
| Power Supply | DC12V |
| Power Consumption | 38W (without HDD) |
| Operating Temperature | -10°C ~ + 55°C (+14°F ~ +131°F) |
| Dimensions | 380mm × 326mm × 53mm (15.0" × 12.8"×2.1") |
| Weight | 2.3 Kg (5.07lb) |
| SOFTWARE | |||
|---|---|---|---|
| Name | Description | Version | Download |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | v1130.3.17.1 | Download |
| EZ Tools | Uniview tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. | v1122.2.6.0 | Download |
| EZ Player | Media player for local recordings. | v1111.1.3.0 | Download |
| Windows Plugin | This is the web plugin for Windows. After installation, you will be able to live view most of Uniview IPC/NVR on IE for Windows. | Download | |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | v1113.3.15.2 | Download |
| MAC Plugin | This is the web plugin for Mac OS. After installation, you will be able to live view most of Uniview IPC/NVR on Safari for Mac. | Download | |
