UNV 8-Channel 16MP UltraHD NDAA Compliant PoE NVR with 2 SATA HDD Bays (NVR502-08B-P8)
- Support Ultra 265/H.265/H.264 video formats
- 8-channel input
- Plug & Play with 8 independent PoE network interfaces
- Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support 1-ch HDMI, 1-ch VGA. HDMI up to 4K (3840x2160) resolution
- VGA and HDMI independent output
- Up to 16 Megapixels resolution recording
- 2 SATA HDD, up to 10TB for each HDD
- ANR technology to enhance the storage reliability when the network is disconnected
- Support cloud upgrade
NVR502-08B-P8
Recorder
16MP
Up to 16MP Resolution
2 SATA HDD
Up to 10TB each
8 POE Ports
Easy Plug-and-Play
3 Year Warranty
Warranty Information
Video recorders are the heart of your cctv system. With the NVR502-08B-P8 you can be sure that your security cameras are in good hands. This IP video recorder is perfect for standard installations with up to 8 security cameras.
The NVR502-08B-P8 is just what your system needs to ensure fast, powerful, and reliable surveillance 24/7.
Easy Plug-and-Play Interface
Connect up to 8 IP cameras to the integrated Power-over-Ethernet (PoE) ports for a truly plug-and-play surveillance experience. Each security camera only requires a single ethernet cable to connect it to the NVR thanks to PoE technology.
This all-in-one ethernet cable provides both power and video transmission to the camera up to 300ft. This means that you won't need to run a separate power cable to your cameras, making installation much easier!
Recording Schedules
If you want 24/7 video recording, the NVR502-08B-P8 NVR is a great choice. You can rest assured that your surveillance system never misses a moment with it's ability to add 2 Hard Drive/s, Up to 10TB each.
You can also setup custom recording schedules based on days and times of the week, or based on events such as motion detection.
NDAA Compliant
This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.
Local & Remote Viewing
This NVR can be used with or without being connected to the Internet. You can view your NVR locally by connecting it to any HD-TV or monitor. If connected to the internet, you are also able to view your NVR remotely by downloading the following app to your smart device.
| SPECIFICATION | |
|---|---|
| IP Channels | 8 |
| Max Resolution | 16MP |
| Max Incoming Bandwidth | 320Mbps |
| Max Outgoing Bandwidth | 160Mbps |
| Video Compression | Ultra H.265|H.265|H.264 |
| Hard Drive Slots | 2 |
| Hard Drive Capacity | Up to 10TB each |
| Synchronus Playback | 8ch |
| Audio I/O | 1ch / 1ch |
| Alarm I/O | 8ch / 2ch |
| Onvif Compatible | Yes |
| Power Supply | 100-240VAC |
| Power Consumption | ≤ 20W (without HDD) |
| Operating Temperature | -10°C~+ 55°C (+14°F~+131°F) |
| Dimensions | 380mm × 322mm × 53mm (15.0"×12.7"×2.1") |
| Weight | ≤ 2.6Kg (5.73lb) |
| SOFTWARE | |||
|---|---|---|---|
| Name | Description | Version | Download |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | v1130.3.17.1 | Download |
| EZ Tools | Uniview tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. | v1122.2.6.0 | Download |
| EZ Player | Media player for local recordings. | v1111.1.3.0 | Download |
| Windows Plugin | This is the web plugin for Windows. After installation, you will be able to live view most of Uniview IPC/NVR on IE for Windows. | Download | |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | v1113.3.15.2 | Download |
| MAC Plugin | This is the web plugin for Mac OS. After installation, you will be able to live view most of Uniview IPC/NVR on Safari for Mac. | Download | |
