UNV 32MP 128-Channel Network Video Recorder with 16 Hard Drive Bays (NVR516-128E-R)
- Support Ultra 265/H.265/H.264 video formats
- 64/128-channel input
- Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support 2-ch HDMI, 2-ch VGA, HDMI1 at up to 8K(7680x4320) resolution, HDMI2 at up to 4K(3840x2160) resolution
- VGA1 and HDMI1 simultaneous output, VGA2 and HDMI2 simultaneous output. VGA1/HDMI1 and VGA2/HDMI2
independent output - Up to 32 Megapixels resolution recording
- Redundant power supply optional
- Support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable
- Support 12V power output
- ANR technology to enhance the storage reliability when the network is disconnected
- Support cloud upgrade
- Support N+1 Hot spare
NVR516-128E-R
Recorder
32MP
Up to 32MP Resolution
16 SATA HDD
Up to 16TB each
3 Year Warranty
Warranty Information
Video recorders are the heart of your cctv system. With the NVR516-128E-R you can be sure that your security cameras are in good hands. This IP video recorder is perfect for larger installations with up to 128 security cameras.
The NVR516-128E-R is just what your system needs to ensure fast, powerful, and reliable surveillance 24/7.
Please note, this recorder does not have an integrated PoE switch.
Recording Schedules
If you want 24/7 video recording, the NVR516-128E-R NVR is a great choice. You can rest assured that your surveillance system never misses a moment with it's ability to add 16 Hard Drive/s, Up to 16TB each.
You can also setup custom recording schedules based on days and times of the week, or based on events such as motion detection.
NDAA Compliant
This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.
Local & Remote Viewing
This NVR can be used with or without being connected to the Internet. You can view your NVR locally by connecting it to any HD-TV or monitor. If connected to the internet, you are also able to view your NVR remotely by downloading the following app to your smart device.
| SPECIFICATION | |
|---|---|
| IP Channels | 128 |
| Max Resolution | 32MP |
| Max Incoming Bandwidth | 640Mbps |
| Max Outgoing Bandwidth | 640Mbps |
| Hard Drive Slots | 16 |
| Hard Drive Capacity | Up to 16TB each |
| Synchronus Playback | 16ch |
| Alarm I/O | 16ch / 10ch |
| Power Supply | AC100 ～ 240V |
| Power Consumption | ≤ 50W |
| Operating Temperature | 14°F ~ 131°F |
| Dimensions | 19.0"×21.0"×5.1" |
| Weight | ~14.3lbs |
| SOFTWARE | |||
|---|---|---|---|
| Name | Description | Version | Download |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | v1130.3.17.1 | Download |
| EZ Tools | Uniview tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. | v1122.2.6.0 | Download |
| EZ Player | Media player for local recordings. | v1111.1.3.0 | Download |
| Windows Plugin | This is the web plugin for Windows. After installation, you will be able to live view most of Uniview IPC/NVR on IE for Windows. | Download | |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | v1113.3.15.2 | Download |
| MAC Plugin | This is the web plugin for Mac OS. After installation, you will be able to live view most of Uniview IPC/NVR on Safari for Mac. | Download | |
